1.   Inverse characteristic

1

DC voltage input range

11-17VDC

2

DC rated input voltage

12.5VDC

3

 Standby power @12.5v input

≤1.5A

DC input 12.5VDC no-load

4

DC input low voltage alarm

10.5±0.2 VDC

Lasts 30 seconds

5

DC input low-voltage protection

10.0±0.2 VDC

Lasts for 2 seconds

6

DC input low voltage shutdown

7.5±0.2VDC，改8.5V
changed to 8.5V

<1mA
DC input current<1mA

7

DC input low voltage recovery

12.5±0.3VDC

Automatic recovery with a delay of 5 minutes

8

DC input high-voltage protection

17±0.3 VDC

9

DC input high voltage recovery

14.5±0.3VDC

Automatic Recovery

10

Over temperature protection

≤65℃

Maximum housing temperature(TC)

11

DC input fuse (built-in)

40A×8

12

DC input polarity reverse connection protection

Blow Fuse

13

No-load AC output voltage

120VAC±5V

14

Full load AC output voltage

120VAC±5V

15

Output rated power

3000W

16

Maximum output power

3050W

5 minutes

17

Output no-load THD

＜3%

18

Output on-load THD

＜5%

Pure resistive load

19

Output overload protection 1

3100~4000w

5 seconds off output

20

Output overload protection 2

4000~4500w

2.5 Seconds off output

21

Output impulse power

≥6000W

22

AC output frequency

60±1Hz

23

Output voltage waveform

Pure sine wave

24

No load on output

Inverter output off

Turn on AC detection for 15 seconds in 1 minute

25

Inverter output ON

At a load of about 10W

Load detection

25

Phase to phase short circuit test

OK

Product protection

26

Inverter conversion efficiency

Maximum efficiency 90%

2. AC mains characteristics

1

AC mains input range

100VAC-120VAC

2

AC mains input rated voltage

120VAC

3

AC mains priority

With mains power

The product is powered on by default, with priority given to mains power output

4

AC mains input frequency switching point

Low frequency cut out 55 ± 1HZ

When the mains voltage is lower than one of the parameter voltages or frequencies. Switch to the inverter output. When switching back to the mains supply, the voltage should be detected for 5 minutes before switching back.

5

Low frequency recovery 56 ± 1HZ

6

High frequency recovery 64 ± 1HZ

7

High frequency cut out 65 ± 1HZ

8

AC mains input voltage switching point

Low voltage cut out 90V ± 5V

9

Low voltage recovery: 100V ± 5V, voltage stabilized for 5 minutes before recovery

10

High voltage recovery 140V ± 5V, voltage stabilization for 5 minutes before recovery

11

High voltage cut out 145 ± 5V

12

AC/DC switching time

<17ms

13

AC mains output rated power single circuit

2400±200W

Product protection

14

AC mains HOT1+HOT2 voltage

240VAC

15

AC mains HOT1+HOT2 power

≤4800W

Ⅲ
Ⅲ

3. Other electrical characteristics

1

LED display

Inverter operation indication

(Inverting active) Orange light (always on)

2

AC mains indication

(AC pass through) Blue light (always on)

3

Protection indication

(Warning) Red light flashing

4

Power indication

(Power) Green light (always on)

5

Searching mode

(Inverting active) Orange light flashes

6

Wired remote control

Wired 15m remote control

Switch on/off, input voltage indication, power indication, and other functions

7

Operating temperature range

-20-40℃
℃

As long as it can start at a low temperature and reduce the load by 10%

8

Storage temperature range

-40-70℃

9

Storage humidity range

5% - 95% without condensation
